STEMME S6 Maintenance Manual

MAINTENANCE MANUAL
STEMME TSA-M
MAINTENANCE MANUAL
STEMME TSA-M
06-30-00
Page 01
ACCESS & INSPECTION PLATES
1. General
A. Accesses / inspection plates on the S6 are used to gain access to various systems, components and
parts of structure during maintenance and for inspection.
B. The access and inspection plates are designated logically.
(1) System of numbering of the access / inspection plates
All access / inspection plates are identified using a series of numbers and letters which specify
zone (see section 06-20-00) and location within this zone. Primary identifiers follow the
three-number sequence, with the first plate identified as „A“, the second as „B“ and so on.
Locators follow the primary identifier and denote top, left, right or internal orientation of the
plate.
Example:
340AL
Vertical Stabilizer left-hand side
First access / inspection plate
In this region
2. Description
A. For an illustration that shows the various accesses / inspection plates used on the S6, refer to
Figure 1.
100 AT Upper Front Gear Cowling
100 BB Lower Front Gear Cowling
100 CB Drain Holes Cabin Heating
200 AT Exhaust Grill
200 BT Upper Cowling
200 CL Upper Left Side Cowling
200 DR Upper Right Side Cowling
200 EB Lower Cowling
200 FB Ext. Power / Batt Charging
610 AB Fuel Drain Port
610 BB Fuel Drain Port
620 AB Drain Holes Airbrake Box
510 AB Fuel Drain Port
520 AB Drain Holes Airbrake Box
300 AT Baggage Compartment Hatch
300 BL Ballast Weight Access Door
300 CB Drain Holes Tailboom Section
EFFECTIVITY
Aircraft equipped with Cabin Heating
Nov 18/11
