GENERAL
1. Introduction
A. This chapter provides a brief general description of the aircraft including a set of technical data.
2. General Description
A. The STEMME S6 is a twin-seat high performance powered sailplane with an innovative
propulsion concept and a sophisticated aerodynamic design. The wing is a carbon fiber reinforced
composite design. The fuselage is manufactured as a hybrid construction (carbon, kevlar, glass)
with an extremely rigid central steel tube framework. The seats are arranged side by side and
equipped with dual controls.
The wing is attached to the fuselage in the upper third section of the fuselage behind the cockpit.
The wing consists of an one-piece central wing with flaps and two outboard wings with Schempp-
Hirth air brakes and inboard and outboard ailerons. The tail unit is designed as a T-tail.
The S6 has a retractable tricycle type landing gear with a steerable nose gear. All three landing
gear legs are equipped with separate gear doors to cover each of the landing gear legs and the
wheel wells completely and aerodynamically. The wheels of the main landing gear are each
equipped with a single disc hydraulic brake assemby.
The engine is located in the middle portion of fuselage, behind the cabin and mounted to a high-
strength steel tube cage. The engine power is transmitted via an internal gear, a composite drive-
shaft and a front reduction gear to a three-blade, constant-speed propeller. The propeller pitch is
controlled electrically.
3. Technical Data
NOTE: For dimensions and areas, also refer to 06-10-00.
A. Overall Dimensions
Wing Span 18,00 m 59.1 ft.
Wing Span Folded 7,20 m 23.6 ft.
2
Wing Area 17,42 m 187.5 ft.
Aspect Ratio 18,62
Length 8,52 m 28 ft.
Height 2,45 m 8 ft.
B. Weights
Maximum Takeoff Weight (MTOW) 900 kg 1984 lbs
Empty Weight 680 kg 1499 lbs
Total Payload 220 kg 485 lbs
2 2
Max. Wing Loading 51,66 kg/m 10.6 lbs/ft
2 2
Min. Wing Loading (empty weight +70kg) 43,05 kg/m 8.8 lbs/ft
02-00-00
Page 01
EFFECTIVITY
Model S6-RT
Nov 18/11
