MAINTENANCE MANUAL
STEMME TSA-M
MAINTENANCE MANUAL
STEMME TSA-M
05-20-00
Page 02
Reference Initials
Motor 100h
Motor 25h
Airframe
100h
Motor 200h
Motor 600h
Motor 1000h
Annual
Type and Subject of Inspection
No.
05-20-00
Page 03
* ROTAX Maintenance Manual (ref. 00-00-00, 2.A), Cha./para.
** mt-propeller, E-118 (ref. 00-00-00, 2.A), /para.
(1) if more than 30% of operation with leaded fuel (AVGAS 100 LL)
1. Check service life limits of all components and
installed equipment.
2.
3. Inspect a/c surfaces and markings (especially
registration and national flag), renew if necessary.
4. Check all drain and ventilation holes.
5. Check all lubrication points and grease if required.
6. Check function of the entire flight control system.
Play allowed (at control surface with control device
fixed, measured in direction of movement):
max. 2.5 mm / 0.1 in
7. Check slackness of aileron, flap and elevator
controls.
Play allowed (hinges):
only axial: 0.4
8. Check friction and forces in the control system.
9. After any maintenance on the control systems,
check deflection of control surfaces and document
values in a report
Thoroughly clean a/c. Remove or open all
necessary inspection plates, access doors, fairings
and cowlings.
± 0.1 mm / 0.016 ± 0.004 in
.
10. After accomplishing maintenance on drive system,
perform an engine run-up.
1. Check fuel system components at spare bridge of
center wing.
2. Check drain valves for leaks.
5.1.2 Wings and Fuel System Components in the Central Wing
5.1.1 General
X
X
X
X
X
X
X
(X)
X
X
X
X
X
X
X
X
X
X
X
(X)
X
X
11-00-00
06-30-00
12-22-00
06-10-00
Nov 18/11
Nov 18/11
5. S6 Inspection Time Interval Chart
A. The maintenance and checks listed in the following chart are to be practiced in the specified
periods and are to be documented in a required manner.
B. S6 Inspection Time Intervals Chart:
