Outputs 170 MDC series
Dual Head Maximum Pump Tube gallons liters gallons liters ounces milliliters liters liters milliliters
Dual Control Pressure Number per day per day per hour per hour per minute per minute per day per hour per minute
Model
Adjustable
170MDCHP9* 100 psi / 6.9 bar #1 0.3 to 5.0 1.1 to 18.9 0.01 to 0.21 0.05 to 0.79 0.03 to 0.44 0.76 to 13.13 0.9 to 15.1 0.4 to 0.63 0.63 to 10.49
170MDC1 25 psi / 1.7 bar #1
170MDCHP34* 100 psi / 6.9 bar 0.8 to 17.0 3.0 to 64.4 0.03 to 0.71 0.13 to 2.68 0.07 to 1.51 2.08 to 44.65 2.4 to 51.5 0.10 to 2.15 1.67 to 35.76
170MDC2 25 psi / 1.7 bar
170MDC3 25 psi / 1.7 bar #2 2.0 to 40.0 7.6 to 151.4 0.08 to 1.67 0.32 to 6.31 0.18 to 3.55 5.27 to 105.14 6.1 to 121.1 0.25 to 5.05 4.24 to 84.10
170MDC4 25 psi / 1.7 bar 3.0 to 60.0 11.4 to 227.1 0.13 to 2.5 0.48 to 9.46 0.27 to 5.33 7.92 to 157.71 9.1 to 181.7 0.38 to 7.57 6.32 to 126.18
170MDC5 25 psi / 1.7 bar 4.3 to 85.0 16.3 to 321.8 0.18 to 3.54 0.68 to 13.40 0.38 to 7.55 11.32 to 223.40 13.0 to 257.4 0.54 to 10.73 9.03 to 178.75
Outputs for Inner Pump Head Only
Approx. Outputs @ 60 Hz Approx. Outputs @ 50 Hz
#1
#2
#3
#4
NOTICE: The information within this chart is solely intended for use as a guide. The output data is an approximation based on pumping water under a controlled testing environment.
Many variables can affect the output of the pump. G. H. Stenner & Co., Inc. recommends that all metering pumps undergo field calibration by means of analytical testing to confirm their outputs.
*pump supplied with injection check valve for 26-100 psi applications
#5
The dial ring for adjustable pumps is marked L-10; L=5%, 1-10 indicates
10% increments of maximum output. (20:1 Turndown Ratio)
