17
Signal
Pin
Relay 2
14
n.a. (In)
15
Relay 3
16
n.a. (out)
17
GND
18-25
PE
shed
5V / VCC
6.5.2 CONNECTOR EXTERNAL SIGNALS / SUB-D 15 (X2)
Connection of external devices to the unit control:
Signal
Pin
Input / Output
19V / 30V VCC
1
Output
GND
2
Output
+5V / VCC Logic
3
Output
Direction 4th axis
4
Output
Step 4th axis
5
Output
Relay 2
6
Output
PW M
7
Output
Tool length sensor
8
Input
19V / 30V VCC
9
Output
GND
10
Output
Disable
11
Input
Reference switch 4th axis
12
Input
Relay 1
13
Output
Relay 2
14
Output
Enclosure
15
Input
PE
shed
6.5.3 CONNECTOR 4TH AXIS / SUB-D 9 (X101)
Connection of motor and reference switch of the 4
th
axis (optional):
Signal
Pin
Winding 1A
1
Winding 1B
2
n.a.
3
n.a.
4
Reference switch 4th axis
5
Winding 2A
6
Winding 2B
7
n.a.
8
GND
9
PE
shed
