Contents Page
Product Specifications
2
BB1230 BB1260 BB122470 BB123670 BB124870 BB241235 BB242435 BBS1230
Input Voltage (V DC) 11 - 20 11 - 20 11 - 20 11 - 20 11 - 20 22 - 40 22 - 40 11 - 20
Solar input voltage (V DC) N/A N/A N/A N/A N/A N/A N/A Up to 31V
Input Current (A) 30 60 70 70 70 35 35 30
Battery types (all models)
IP rating IP21 IP21 IP21 IP21 IP21 IP21 IP21 IP21
Ignition Protected Yes Yes Yes Yes Yes Yes Yes YES
Quiescent Current (mA) 1 1 1 1 1 1 1 1
Battery Connector WJ116VW WJ116VW WJ116VW W J116VW WJ116VW
Weight (Kg) 1.2 1.4 1.4 1.4 1.4 1.4 1.4 1.4
Dimensions (LxWxD) mm 190 x 160 x 50 190 x 160 x 50
AGM | GEL | SEALED | OPEN | LiFePO4 (2) | CALCIUM | CUSTOM
8mm input | WJ116VW output
Legal and Safety Information Page 3 Automatic | Ignition Feed Modes Page 9
How to use the instructions Automatic activation (non ignition mode)
Copyright and Plagiarism 2x Ignition feed modes EURO 6
Maintenance and Repair First time use Page 10
Safety and Precautions Changing battery profile type
Front Panel Display I Page 4 First and second LED column meter readings
Front Label display annotated Guide to the 2 buttons Page 11
What the LEDs mean Simplified chart corresponding to button use
Front Panel Display II Page 5 FACTORY RESET
Under the red end cap Force Option feature explanation Page 12-13
Scaled dimensions of the BB Detailed description of button / force functions
Cable and fuses guide Custom Settings Page 14-15
Installation Diagram (non Solar) Page 6 How to set a custom charge profile
wiring diagram for installation Adjusting bulk / absorption / float / times
temperature sensor install Adjusting operation on / off voltages
BMS connectors operations Remote Control Operations Page 16
Remote voltage sense use Comprehensive breakdown of remote functions
Installation SOLAR BBS1230
Page 7 Troubleshoot | understanding panel LEDs Page 17
wiring diagram for installation Fault Finding Page 18
Fundamental fault + troubleshootings
Lithium Battery Installation Page 8 LED displays w/ meanings and solutions
Lithium Battery Charging Profiles Sterling's Warranty Statement Page 19
External and Internal BMS shutdowns Customer service and warranty declaration
0 Deg C temperature sensor trip
