Sterling S400 - Control System Operation; Control Console Layout and Functions

24
Sterling S-Series
7.0 Scooter Control System
7.1 SCOOTER CONTROL CONSOLE
Fig.7.1
7.1.6 LIG HTS
7.1.5 INDICATORS
7.1.4 HAZARD LIGHTS
7.1.3 HORN
7.1.8 BATTERY LEVEL GAUGE
7.1.7 SPEED CONTROL
7.1.5 INDICATORS
7.1.9 50% SPEED PROFILE
Fig.7.2
7.1.1 KEY SWITCH
7.2 CHARGER SOCKET
TILLER ADJUSTER
Fig.7.3
7.1.2 CONTROL LEVER
(WIG-WAG)
