FLUSH VALVE INSTALLATION
1. Ensure that the central water supply has been turned off at the corner valve.
2. Install the flush valve on
the wall connected to the
mains water supply.
3. Use the sealing thread or
Teflon tape to seal the screw
thread connection. Fit the
wall flange between the inlet
opening of the regulating
valve and the surface of the
wall.
4. Insert the inlet pipe and rubber seal into the opening in the urinal.
5. Push the inlet pipe into the water outlet opening of the flush valve and tighten the
locking screw.
6. Turn on the mains water supply again
and check the installation for leaks.
7. Ensure that the regulating valve is fully
open by turning it anti-clockwise.
8. Remove the sticker that is covering the
sensor. The battery is already connected
and the flush valve is now operational.
9. Carry out functional check. If the
sensor coverage area is not adequate
it can be readjusted following the
procedure in the “Settings adjustment”
section.
