12
EN-US
Resources
The equalizer has 2 input channels and 3 output channels, namely:
The equalizer counts with rotary controls for adjustment and equalization of signal in
conforming audio wanted:
• SUB output control: Set the level and SUB output frequency.
• Input switch: Select the input signal channel (MAIN or HIGH).
• Input controls: Individual LEVEL adjustment in each input (HIGH or MAIN).
• FADER FRONT/REAR control: Set the balance between the FRONT and REAR outputs.
• LED lighting: For better control visualization, they lit on a LED frame, at color BLUE.
• Frequency controls: Equalizer with 7 bands (50Hz / 125Hz / 315Hz / 750Hz / 2.2KHz
/ 6KHz / 16KHz).
Introduction
Thank you so much for choosing a STETSOM product! The equalizer was developed with the
most advanced technology for adjustment and audio equalization with high-fidelity sound.
MAIN IN: RCA connection ( L + R )
SUB OUT: RCA ( L + R )
HIGH-IN: HIGH connection ( L + R )
REAR OUT: RCA ( L + R )
INPUT
OUTPUT
FRONT OUT: RCA ( L + R )
RCA CONNECTION (LINE)
Usual on many radios and
audio equipment on the
market.
HIGH CONNECTION (WIRE)
Usual at various originals
radio players of the vehicle.
INPUT CONNECTIONS
