STIEBEL ELTRON SHC 2.5 Installation And Operating Instructions

4
1. GENERAL INFORMATION
These SHC water heaters can be used in
most point-of-use applications. They are
designed to supply hot water for all hand
wash and kitchen sinks in a residential,
commercial or industrial environment.
These water heaters can replace
traditional hot water systems which
consist of a central hot water heater with
hot water piping going to several draw-off
points.
The SHC water heaters are lightweight
and compact and manufactured for easy
installation. The units are designed to be
mounted on the wall.
2. TECHNICAL DESCRIPTION
There are two SHC models available, a
2.5 gallon model and a 4 gallon model.
The pressure vessel of the water heater is
welded glass-lined steel and is equipped
with a sacrificial anode rod. The thermal
insulation is polystyrene.
The water heater is equipped with both a
thermostat and high limit temperature
switch.
A temperature/pressure relief valve is
supplied with the unit.
These units are designed to operate
under normal street water pressure.
TECHNICAL SPECIFICATIONS
Model SHC 2.5 SHC 4
Phase 1 1
Voltage
V
110 - 120 110 - 120
Wattage W 1200 1200
Amperage
A
11 11
Nominal water volume Gal /
L
2.65 / 10 3.96 / 15
Weight empty Lbs / k
g
19.84 / 9 22 / 10
Height Inch / cm 18.19 / 46.2 18.19 / 46.2
Width Inch / cm 11.42 / 29 12.28 / 31.2
Depth Inch / cm 11.42 / 29 12.28 /31.2
Maximum operating pressure PSI / Ba
r
150 / 10 150 /10
Maximum adjustable
temperature
ºF / º
C
171º / 77º 171º / 77º
Recovery time Mi
n
45 60
Water connections 1/2” NPT 1/2” NPT
PLEASE RETAIN THESE INSTRUCTIONS IN A SAFE LOCATION FOR
FUTURE REFERENCE.
