www.stiebel-eltron.com WPF | WPF cool | 77
INSTALLATION
Specication
WPF 05 S WPF 07 S WPF 10 S WPF 13 S
Weights
Weight kg 152 157 169 171
Connections
DHW flow/return plug-in connection 28 mm 28 mm 28 mm 28 mm
Heat source flow/return plug-in connection 28 mm 28 mm 28 mm 28 mm
Heating flow/return plug-in connection 28 mm 28 mm 28 mm 28 mm
Values
Available external pressure differential, heating system hPa 554 444 440 282
Available external pressure differential; heat source hPa 591 732 660 520
Rated heating flow rate m³/h 0.71 0.92 1.26 1.64
Heating flow rate (min.) m³/h 0.57 0.74 1.00 1.27
Heating flow rate (EN 14511) at A7/W35, B0/W35 and 5 K m³/h 1.00 1.29 1.76 2.25
Flow rate, heat source side m³/h 1.45 1.76 2.54 3.13
Expansion vessel pre-charge pressure, heating side MPa 0.15 0.15 0.15 0.15
Expansion vessel volume, heating side l 24 24 24 24
Expansion vessel pre-charge pressure, source side MPa 0.05 0.05 0.05 0.05
Expansion vessel volume, source side l 24 24 24 24
Conversion: 1 m
3
/h = 16.67 l/min
