STIEBEL ELTRON WPL 10 A User Manual

6 | WPL 10 www.stiebel-eltron.com
INSTALLATION
Safety
INSTALLATION
7. Safety
Only a qualified contractor should carry out installation, commis-
sioning, maintenance and repair of the appliance.
7.1 General safety instructions
We guarantee the trouble-free function and operational reliabil-
ity only if original accessories and spare parts intended for the
appliance are used.
7.2 Instructions, standards and regulations
Note
Observe all applicable national and regional regulations
and instructions.
8. Appliance description
For outdoor installation the appliance offers additional frost pro-
tection of the heating water pipes. The integral frost protection
circuit starts the heating circuit pump in the heat pump circuit
automatically at +8°C condenser temperature, and thereby en-
sures circulation in all water-filled sections.
The heat pump starts automatically when the temperature in the
heat pump circuit drops below +5°C.
8.1 Standard delivery
8.1.1 WPL 10 I
The following are delivered with the appliance:
- Wiring diagram
8.1.2 WPL 10 IK 3
The following are delivered with the appliance:
- 2 x air hose with fixing materials
- Wiring diagram
8.2 Accessories
Designation
Heat pump manager in wall mounted enclosure, WPMW (WPL10I only)
Pressure hoses SD25 or SD32
Wall duct with external wall grille AWG315SR
Wall duct with external wall grille AWG315GL
Thermally insulated air hose, 4m (WPL10I only)
Hose connection panel
Condensate pump PK10
Cylinder SBP200E
Cylinder SBP400E
Cylinder SBP700E
Heat pump manager in wall mounted enclosure, WPMW (WPL10I only)
Heat pump manager as control panel mounted version, WPMS (WPL10I only)
Mixer module with wall mounting enclosure, MSMW
Designation
Mixer module as control panel mounted version, MSMS
Pressure hose G 1¼” x 1m
Pressure hose G 1¼” x 2 m
Pressure hose G 1¼” x 5 m
Pressure hose G 1¼” x 10 m
Heat pump compact installation WPKI 5
UP kit 25 / 7E (for WPKI5)
Remote control for heating systems FE 7
Contact sensor AVF 6
Immersion sensor TF 6
STB-FB safety temperature controller for underfloor heating
Filter assembly 22 mm (FS-WP 22)
Filter assembly 28 mm (FS-WP 28)
