ENGLISH
EN
8.9.4 Fault: Slips when moving forward.
Reason: The belt is too slack.
Procedure: Adjust the belt.
8.9.5 Fault: Slips when moving backward.
Reason: The gear control is incorrectly adjusted.
Procedure: Adjust the gear control.
8.9.6 Fault: Stops under operation.
Reason: Run out of fuel.
Procedure: Fill up with petrol.
9 TECHNICAL DATA
Weight: 46 kg
Type of engine: 4-stroke, Briggs & Stratton
Spark plug: Champion QC12YC or the equivalent.
Power: 4 kW (5.5 hp)
Engine speed: 3400 rpm
Sound pressure
level: 77 dB(A)
Vibration level: 2.9 m/s
2
Transmission: Belt gear with gearbox
Fuel tank, capacity: 2.8 litres
Fuel: 95 octane, unleaded petrol
Steering handles: Vertically adjustable.
Blade diameter: 320 mm
Working width: 590 mm (840 mm with 6 rotors and
340 mm with 2 rotors)
Rotation of blades
forward: 135 rpm
Rotation of blades
backward: 58 rpm
10 CE CERTIFICATE
Ets PUBERT SA Z.I. de Pierre-Brune, 85110 CHANTON-
NAY, France warrants that tiller JB 55 complies with the es-
sential health and safety requirements in the directives 89/
392 CEE and 98/37/CE. To guarantee correct application of
the safety and health requirements stipulated in the EEC Di-
rective, the following standards and/or technical specificati-
ons have been consulted: EN 292-1, EN 292-2, EN 25349
(1993) and NFU 02-025.
Chantonnay 01 01 99
M. Jean-Pierre PUBERT
Chairman and CEO
