3 AREAS OF USE
The machine may only be used for the following
tasks using the genuine STIGA accessories stated.
1. Mowing
With cutting deck 13-2939 (92M).
2. Snow clearance
With snow blade 13-0918. Snow chains 13-
0936 (16”) and frame weights 13-0923
recommended.
3. Grass and leaf transport
With dump cart 13-1979 (Standard).
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing hitch
from towed accessories must not exceed 500 N.
NOTE! Before using a trailer – contact your
insurance company.
NOTE! This machine is not intended to be driven
on public roads.
4 STARTING AND OPERATION
4.1 ENGINE CASING
To fill with fuel and to inspect and maintain the
engine and battery, open the engine casing. The
engine must not be running when the casing is
opened.
Opening:
1. Raise the seat lock (fig. 4) and fold the seat
forwards.
2. Pull up the rubber strap at the front edge of the
casing (fig. 5).
3. Grasp the front edge of the engine casing and
fold up the casing (fig. 6).
Closing:
1. Grasp the front edge of the engine casing and
fold down the casing (fig. 6).
2. Secure the front edge of the casing with the
rubber strap (fig. 5).
The machine may not be operated
unless the engine casing is folded down.
Risk of burns and crushing injuries.
4.2 FILLING THE FUEL TANK
Open the engine casing as above. Unscrew the
filler cap and fill with clean, lead-free petrol. You
must never use 2-stroke petrol mixed with oil (fig.
7).
NOTE! Bear in mind that ordinary lead-free petrol
is a perishable; do not purchase more petrol than
can be used within thirty days.
Environmental petrol can be used, i.e. alkylate
petrol. This type of petrol has a composition that is
less harmful for people and nature.
Petrol is highly inflammable. Always
store fuel in containers that are made
especially for this purpose.
Only fill or top up with petrol outdoors,
and never smoke when filling or
topping up. Fill up with fuel before
starting the engine. Never remove the
filler cap or fill with petrol while the
engine is running or still warm.
Never completely fill the petrol tank. Leave an
empty space (= at least 2-3 cm at the top of the
tank) to allow the petrol to expand when it warms
up without overflowing.
4.3 CHECKING THE ENGINE OIL
LEVEL
On delivery, the crankcase is filled with SAE 30
oil.
Check the oil level every time before using to
ensure it is correct. The machine should be
standing on level ground.
Wipe clean around the oil dipstick.
Unscrew and pull it up. Wipe off the
dipstick. Slide it down completely and
tighten it.
Then unscrew it and pull it up again. Read off the
oil level. Top up with oil to the “FULL” mark, if
the level comes below it (fig. 8).
4.4 CHECKING THE
TRANSMISSION OIL LEVEL
(Compact HST)
The transmission is filled with SAE 10W-40 oil
when the machine is delivered from the factory,
Check the oil level every time before using to
ensure it is correct. The machine should be
standing on level ground.
Read off the oil level in the reservoir (fig. 9). It
should be between the MAX and MIN marks. If
necessary, top up with more oil. Use oil SAE 10W-
40 (20W-50).
4.5 SAFETY SYSTEM
This machine is equipped with a safety system that
consists of:
- a switch on the transmission (only Compact).
- a switch on the break pedal (only
Compact HST).
- a switch in the seat/seat bracket.
- a switch at the power take-off engagement
lever.
In order to start the machine, the following are
necessary:
- gear lever in neutral (only Compact).
