ENGLISH
EN
- the break pedal depressed (only
Compact HST).
- driver sitting on seat.
- power take-off disengaged.
Always check the operation of the
safety system before using the machine!
With the engine running and the driver sitting on
the seat, check as follows:
- select a gear, lift your weight off the seat – the
engine must stop (only Compact).
- press the drive pedal so that the machine starts
to move, release the drive pedal – the machine
should stop (only Compact HST).
- engage the power take-off, lift your weight off
the seat – the engine should stop.
Do not use the machine if the safety
system is not working! Take the
machine to a service workshop for
inspection!
4.6 STARTING ENGINE
1. Open the fuel cock (fig. 7).
2. Make sure that the spark plug cable is properly
in place.
3. Check to make sure that the power take-off is
disengaged.
4a. Compact: Put the gear lever in neutral.
4b. Compact HST: Do not keep your foot on the
drive pedal.
5. Starting cold engine – put the throttle control in
the choke position. Starting warm engine – put
the throttle control at full throttle (approx. 1 cm
behind the choke position).
6. Depress the brake pedal fully.
7. Turn the ignition key and start the engine.
8. Once the engine has started, move the throttle
control gradually to full throttle if the choke has
been used.
9. When starting from cold, do not make the
machine work under load immediately, but let
the engine run for a few minutes first. This will
allow the oil to warm up.
When in use, always operate the engine at full
throttle.
4.7 STOPPING
Disengage the power take-off. Apply the parking
brake.
Allow the engine to idle 1 - 2 mins. Stop the engine
by turning off the starter key.
Shut off the petrol cock. This is particularly
important if the machine is to be transported on a
trailer for example.
If the machine is left unattended,
remove the spark plug cable from the
spark plug. Also remove the starter key.
The engine may be very warm
immediately after it is shut off. Do not
touch the silencer, cylinder or cooling
fins. This can cause burn injuries.
4.8 DRIVING TIPS
Make sure that there is the correct quantity of oil in
the engine when driving on slopes (oil level on
“FULL”).
Be careful when driving on slopes. No
sudden starting or stopping when
moving up or down a slope. Never drive
across a slope. Move from the top down,
and from the bottom to the top.
The machine, equipped with original
accessories, may not be driven on slopes
greater than 10º in any direction.
Reduce the speed on slopes and when
making sharp turns to prevent the
machine from tipping over or you
losing control of the machine.
Do not turn the steering wheel to full
lock when driving in top gear and at full
throttle. The machine can easily topple
over.
Keep hands and fingers well away from
articulated steering joint and seat
bracket. Risk of crushing injuries.
Never operate the machine without the
engine casing.
5 SERVICE AND
MAINTENANCE
5.1 SERVICE PROGRAM
In order to keep the machine in good condition, as
regards reliability and operational safety as well as
from an environmental perspective, STIGA’s
service program should be followed.
The contents of this program can be found in the
attached service log.
We recommend that all service work is carried out
by an authorised workshop. This guarantees that
the work is performed by trained personnel and
with genuine spare parts.
At every service, the service log should be
stamped. A “fully stamped” service log is a
valuable document that improves the machine’s
second-hand value.
