2008-03-17 Workshop Manual, Stiga Primo 5 Electrical System 1
5 Electrical System
Contents in this chapter
General
The electrical system has two main duties, to maintain the machine safety and to make the
different functions easy to handle.
The main part of this chapter consists of trouble shooting of the electrical system to isolate
faults and to give information about corrective measures. The electrical system is also
described. There are also given instructions about general repair and replacement
procedures.
5.2.6 The motor can be started with a
gear activated.............................6
5.2.7 The motor does not stop when the
operator leaves the seat and the
mover deck is activated ..............7
5.3 Repair and replacements..............8
5.3.1 Connections ...............................8
5.3.2 Circuit diagram ...........................9
5.1 Description.....................................2
5.2 Trouble Shooting........................... 3
5.2.1 The starter does not rotate.........4
5.2.2 The starter rotate, but the motor
does not start..............................5
5.2.3 The battery runs repeatedly
empty..........................................5
5.2.4 The motor does not stop............6
5.2.5 The motor can be started with the
mover deck activated .................6
