Stiga Primo 2008 - 6.3.2 Assembly

Edition Manual Product Page
2008-03-18 Workshop Manual, Stiga Primo 6 Mower Decks 6
6. Hook off the deck from the front axes and take
it out in the forward direction. See the figure.
6.3.2 Assembly
Install the cutting deck as follows:
1. Hook the deck over the front axles.
2 Install the locking screws (L) on both sides.
3. Set the maximum cutting height.
4. Raise the deck and hook on the lift cable (K).
L x2
K
