WORKSHOP MANUAL
T...102/122 - TC...102/122
Map of functional units
All work can be carried out using the tools normally
a vailable from a good workshop. However, it is ad vi-
sable to have a set of special tools (1 ÷ 8).
These tools (1 ÷ 8) are to be used whenever is given
in the text.
1. Blocks H = 26 mm for adjusting the cutting deck
2. Blocks H = 32 mm for adjusting the cutting deck
3. Bush for assembly of blades bearings
4. Stopper for assembly of wheel bearings
5. Pulley extractor
6. Pulley centre distance checking template
7. Blades connection belt tension checking template
8. Dynamometer
Validity
General informations
This chapter covers the main aspects of a servic
ing procedure and the general rules for guaran
teeing a successful service which respects the
safety of the machine.
Related topics
---
TOOLS
CHAPTER REVISION FROM ... PAGE
2.2 0 2018 1 of 1
