Detail F
13. Lay out Rails (#2, #3, & #23) around edges of
table top. See Figure 8.
14. Line up holes in rails with Indentations in table top
and secure using Screws (#5). See Figure 8 &
Detail F.
2
23
23
Figure 8
*NO
TE: Legs not
shown for clarity.
