. immersing it In an oil bath. If you are not going to use the
chain for a prolonged period, clean it with a brush and
immerse it In an oil-paraffin bath.
Carefully examine chain for cracks in'the links or damaged
rivets while you are sharpening and cfeanlng it. Any dama-
ged or worn parts' must be replaced. The new parts must
be reworked to match the shape and size of the original
parts.
Chain repairs can be > carried out With the STIHL handheld
chain breaking and riv~ spinning tool, the STlHL NG 1 or
NG 5 rivet spinners and the STIHL NG 4 chain breaker.
Tools for chain maintenance
There is a range of chain sharpening aids and tools to suit
the
users needs (frequency of sharpening, time required
etc.).
FIle holders, which have reference marks for the filing
angle, stmpllfy chain sharpening and are aval1ab1e for all ty-
pes of chain.
The FG 1 filing tool attaches to the guide bar and shar-
pens all types of chain.
The STlHL FG 2 Filerlte and USG universal electric
sharpener are workshop tools suitable for sharpening ail
types of chain.
Table of file holders
Chain pitch
inch(mm)
.325 (8.25)
.325 (8.25)
.325 (8.25)
.325 (8.25)
%
(9.32)
%
(9.32)
%
(9.32)
%
(9.32)
%
(9.32)
.404 (10.26)
.404 (10.26)
.404 (10.26)
Chain File holder
Part No.
Rapid~Micro
• 5605 750 4326
RaPid-8uper
5605 750 4336'
Topic-Micro 5605 750 4321
Topic-Super
5605 7504351
Rapid-siandard
56057504326'
Rapid-Micro
5605 750 4326
Rapid-Super
5605 750 4336
Topic-Micro
5605 7504321
Topic-Super
5605 750 4351
Rapid-Standard
5605 750 4326
Rapid-Micro
5605 750 4326
Rapid-Super
5605 750 4336
43
