Stihl BR 800 C User Manual

7 Fueling
7.1 Preparations
452BA123 KN
► Before fueling, clean the filler cap and the area
around it to ensure that no dirt falls into the
tank.
7.2 Opening screw-type tank cap
002BA447 KN
► Turn the cap counterclockwise until it can be
removed from the tank opening.
► Remove the cap.
7.3 Filling up with fuel
Take care not to spill fuel while fueling and do
not overfill the tank. STIHL recommends you use
the STIHL filler nozzle (special accessory).
7.4 Closing screw-type tank cap
002BA448 KN
► Place the cap in the opening.
► Turn the cap clockwise as far as stop and
tighten it down as firmly as possible by hand.
8 Winter Operation
8.1 At temperatures below +10°C
1
2
3
0000-GXX-5388-A0
► Loosen the screws (1).
► Remove the filter cover (2) together with the
air filter (3).
4
0000-GXX-5389-A0
►
Move the shutter (4) to the right to position r
(winter operation).
► Fit the filter cover (2) with air filter (3) in posi‐
tion.
► Insert the screws (1) and tighten them down
firmly.
7 Fueling English
0458-490-8321-B 11

Stihl BR 800 C Specifications

General

Engine Displacement	79.9 cc
Air Velocity	239 mph
Air Volume	1, 600 m³/h
Power Source	Gasoline
Displacement	79.9 cm³
Fuel Capacity	1.3 L
Blowing Force	41 N
Power output	3.2 kW
Fuel tank volume	1400 ml
Vibration level left/right	2.5 m/s²
Air speed	239 mph
