► Carefully rotate the screw in the throttle trigger
in the direction of the arrow until you feel initial
resistance. Then rotate it another half turn in
the same direction.
5 Fitting the Harness
5.1 Adjusting the Harness
A
B
271BA047 KN
A Pull the straps to tighten the harness
B Lift the tabs of the adjusters to loosen the
straps
C
D
271BA048 KN
C Close the buckle by pushing the two parts
together.
D Squeeze the hooks to open the buckle.
5.2 Fitting the harness
1
2
0000-GXX-6235-A0
► Put the blower on your back.
► Close the buckle on the waist belt (1).
