ZyAIR Wireless LAN Utility
3-10 Using the ZyAIR Utility
Table 3-5 ZyAIR Utility: Site Survey
FIELD DESCRIPTION
Connect
Click Connect to associate to the selected wireless device.
The following table describes the colors used for the entries in the Site Survey screen.
Table 3-6 Color Indicator for Link Quality/Link Strength
COLOR DESCRIPTION
Green Excellent link quality or link strength.
Blue Good link quality or link strength.
Red Poor link quality or link strength.
3.7.1 Connecting to a Network
Follow the steps below to connect to a network.
Step 1. Click Search to scan for all available wireless networks within range.
Step 2. To join a network, either click an entry in the table to select a wireless network and then click
Connect or double-click an entry.
Step 3. If the WEP field is Enable for the selected wireless network, the following screen displays.
Figure 3-9 Site Survey Warning
Step 4. Click OK to display the Security screen and refer to Section 4.2 to set up WEP keys. Otherwise
click Cancel and connect to another wireless network without WEP encryption.
Step 5. To verify that you have successfully connected to the selected network, check the network
information in the Link Info screen.
3.8 Configuring the ZyAIR Wireless Parameters
Click Configuration in the ZyAIR Utility program to display the Configuration screen as shown next.
