ZyAIR Wireless LAN Utility
5-4 Advanced Configuration
Table 5-1 ZyAIR Utility: Advanced
FIELD DESCRIPTION
Transmit Threshold Control
Fragmentation
Threshold
The threshold (number of bytes) for the fragmentation boundary for directed
messages. It is the maximum data fragment size that can be sent.
Move the slider to set the fragmentation threshold.
RTS/CTS Threshold Data with its frame size larger than this value will perform the RTS/CTS handshake.
Setting this attribute to be larger than the maximum MSDU (MAC service data unit)
size turns off the RTS/CTS handshake. Setting this attribute to zero turns on the
RTS/CTS handshake.
Move the slider to set the RTS/CTS threshold.
Security
Shared Mode
(Authenticate Access
Point)
Select this checkbox to use a shared key to authenticate the access point.
Refer to Section 5.1.2 for more information.
Preamble Type
Select a preamble type from the drop-down list menu. Choices are Long Preamble,
Short Preamble and Auto.
The default setting is Auto.
Refer to Section 5.1.3 for more information.
Restore Default
Click Restore Default to reset all fields back to factory default values.
Undo Changes
Click Undo Changes to start configuring the fields again.
Apply Changes
Click Apply Changes to save the changes back to ZyAIR.
