7FS 240 C, FS 260 C, FS 360 C, FS 410 C, FS 460 C-M
Fastener Thread size For component Tightening
torque
Nm
Comment
Screw M 5x20 Clamp/ control handle for loop handle/ nut 4.5 1)
Screw M 5x20 Cutting attachment deflector/ gear housing 4.3 1)
Screw M 5x23 Cutting attachment deflector/ gear housing 10.0
Screw IS 5x14 Deflector/ antivibration housing 4.0 6)
Screw D 5x32 Protective hip plate/ crankcase 8.0 1)
Nut M 8x1 Flywheel/ crankshaft 28.0
Screw M 6x14 Clamp/ drive tube assembly harness anchor 4.5 1)
Screw D 6x32 Clamp/ drive tube assembly with washer 12.0 1)
Screw M 5x18 Clamp/ supports/ drive tube assembly 4.0 1), 6)
Nut M 8x1 Starter cup / crankshaft 17.0
Screw P 6x19 Supports/ plugs antivibration springs 6.0 6)
Screw M 14x1.25x7 Supports/ muffler with spark arresting screen 8.0
Screw P 4x14 Bushing choke/ filter housing 2.0
Screw P 4x10 Shim/ deflector 1.0
Screw M 11x10 Screw plug/ gearbox 9.5
M 10x1 Spark plug/ cylinder 12.0
Screw D 4x18 Ignition module/ cylinder 4.0 1)
Screw M 5x20 Spacer flange/ cylinder 8.0 2)
Screw D 5x32 Cylinder / crankcase 9.0 1)
Remarks:
1) Easy-slide coating with locking serration
2) Microencapsulated with locking serration
3) Microencapsulated with washer
4) Connection between crankshaft and flywheel must be degreased and oil-free
5) 1-point antivibration system
6) 4-point antivibration system
7) M-Tronic
When inserting DG and P screws into an existing screw thread:
Insert the DG or P screw in the hole and turn counterclockwise until it gently drops into the hole in axial direction.
Tighten the screw clockwise to the specified torque.
This procedure ensures that the screw engages properly in the existing thread and does not form a new thread
and weaken the assembly.
As a rule, microencapsulated screws must be replaced after removal.
Screwdriver speed when used in plastic material: max. 500 rpm for DG and P-type screws.
Do not use an impact wrench to release or tighten screw connections.
Screws with and without locking serration must not be confused.
