Stihl FS 45 User Manual

FS 45, FS 46
English
22
Controls
1 Stop switch
2 Throttle trigger lockout
3 Throttle trigger
4 Tongue of throttle trigger
5 Catch
Positions of stop switch
6I – normal run position – the engine
is running or can start
70 – Stop – engine off – the ignition is
switched off
Starting
N Move the stop switch to I.
N Press down the throttle trigger
interlock and hold it there.
N Squeeze the throttle trigger until the
catch on the tongue (4) can be
engaged on the housing (arrow).
N Now release the throttle trigger,
tongue and trigger interlock in that
order. This is the starting throttle
position.
N Set the choke lever (8) to
N Press the fuel pump bulb (9) at least
five times – even if the bulb is
already filled with fuel.
Starting / Stopping the
Engine
2
232BA080 KN
1
6
7
5
4
3
233BA047 KN
4
g if the engine is cold
e for warm start – also use this posi-
tion if the engine has been running
but is still cold.
9
8
232BA011 KN

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
