Stihl FS 45 User Manual

FS 45, FS 46
English
34
1 Loop Handle
2 Spacer
3 Stop Switch
4 Throttle Trigger Lockout
5 Throttle Trigger
6 Choke Lever
7 Air Filter Cover
8 Fuel Filler Cap
9 Fuel Tank
10 Machine Support
11 Fuel Pump
12 Carburetor Adjusting Screws
13 Starter Grip
14 Spark Plug Boot
15 Muffler with Spark Arresting Screen
16 Line Limiting Blade
17 Deflector
18 Mowing Head
19 Drive Tube
# Serial Number
Main Parts
13
11
12
2
8
6
5
4
3
1
7
9
10
#
15
14
16
17
18
19
232BA076 KN

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
