Stihl GHE 135 L User Manual

EN
23
0478 201 8312 B - EN
Fault:
Motor does not start
Possible cause:
– Shredder box not inserted and locked in
place
– Motor overload protection activated
– No mains voltage
– ConnectorConnection cable, plug, plug
connector or switch defective
Remedy:
– Insert shredder box and lock in place
(Ö 10.5)
– Allow machine to cool down (Ö 8.6)
– Check power cable and fuse
# (Ö 10.1)
– Check cable, plugs, connector and
switch and replace if necessary (by
electrician) # (Ö 10.1)
Fault:
Shredding material is not drawn in
Possible cause:
– Blade roller is blocked
Remedy:
– Remove blockage (Ö 10.9)
Fault:
Shredding material is not cut
Possible cause:
– Counterplate on the blade roller not
properly adjusted
– Blade roller worn or damaged
Remedy:
– Adjusting the counterplate (Ö 11.1)
– Replace blade roller and counterplate
#
Fault:
Motor is humming, machine does not start
Possible cause:
– Blade roller is blocked
Remedy:
– Remove blockage (Ö 10.9)
Fault:
Abnormal noises, machine rattles
Possible cause:
– Screws loose
– Blade roller worn or damaged
Remedy:
– Check that all screws are securely
seated; tighten loose screws
– Replace blade roller and counterplate
#
Fault:
Shredding material is not ejected
Possible cause:
– Ejection chute obstructed by incorrectly
positioned rubber cover
Remedy:
– Install rubber cover correctly (Ö 7.2)
Protection class II
Type of protection Splash proof (IP
X4)
Operating conditions P40
40 s load time
60 s idle time
L/W/H 64/49/96 cm
GHE 135.0 L:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
94 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
87 dB(A)
Uncertainty K
pA
3 dB(A)
Power 2000 W
Amperage rating 10 A
Nominal motor speed 21000 rpm
Weight 23 kg
GHE 140.0 L:
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
93 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
85 dB(A)
Uncertainty K
pA
3 dB(A)
Power 2000 W
Amperage rating 10 A
Nominal motor speed 21000 rpm
Weight 24 kg
GHE 135.0 L, GHE 140.0 L:
16. Troubleshooting
# If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
