KM 56 R, KM 56 RC
English
12
N Hold the starter grip with your right
hand.
Version without ErgoStart
N Pull the starter grip slowly until you
feel it engage and then give it a brisk
strong pull.
Version with ErgoStart
N Pull the starter grip steadily.
NOTICE
Do not pull out the starter rope all the
way – it might otherwise break.
N Do not let the starter grip snap back.
Guide it slowly back into the housing
so that the starter rope can rewind
properly.
N Continue cranking until engine runs.
As soon as the engine runs
N Press down the throttle trigger
lockout and open the throttle – the
choke lever moves to the run
position F. After a cold start, warm
up the engine by opening the
throttle several times.
WARNING
Make sure the carburetor is correctly
adjusted. The working tool must not
rotate when the engine is idling.
Your machine is now ready for
operation.
Stopping the Engine
N Move the stop switch in the direction
of 0 – the engine stops – release
the stop switch – it springs back to
the run position.
Other Hints on Starting
Engine stalls in cold start position g or
under acceleration
N Move the choke lever to < and
continue cranking until the engine
runs.
Engine does not start in warm start
position <
N Move the choke lever to g and
continue cranking until the engine
runs.
If the engine does not start
N Check that all settings are correct.
N Check that there is fuel in the tank
and refuel if necessary.
N Check that the spark plug boot is
properly connected.
N Repeat the starting procedure.
Fuel tank run until completely dry
N After refueling, press the manual
fuel pump bulb at least five times –
even if the bulb is filled with fuel.
N Set the choke lever to suit the
engine temperature.
N Now start the engine.
547BA020 KN
547BA021 KN

Stihl KM 56 RC Specifications

General

Displacement	27.2 cm³
Fuel Capacity	0.33 l
Power Source	Gasoline
Idle Speed	2, 800 rpm
Fuel Tank Capacity	0.33 l
Engine Power	0.8 kW
Engine	2-stroke
Ignition System	Electronic
Starter System	STIHL ErgoStart (E)
