Stihl KM 56 RC User Manual

KM 56 R, KM 56 RC
English
20
Engine
Single cylinder two-stroke engine
Ignition System
Electronic magneto ignition
Fuel System
All position diaphragm carburetor with
integral fuel pump
Weight
Sound and Vibration Levels
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib
KombiTool
For version see "Approved
KombiTools".
To determine the noise and vibration
values, idle speed and nominal
maximum speed are considered in the
following ratios:
The exact noise and vibration
specifications depend on the KombiTool
being used and are described in the
User Manual of the KombiTool.
Sound pressure level L
peq
measured
according to ISO 22868, ISO 11201,
ISO 11789
Sound power level L
w
measured
according to ISO 22868, ISO 3744
Vibration level a
hv,eq
to ISO 20643,
ISO 22867, ISO 11789
The K
-
factor in accordance with
Directive 2006/42/EC is 2.0 dB(A) for
the sound pressure level and sound
power level; the K
-
factor in accordance
with Directive 2006/42/EC is 2.0 m/s
2
for the vibration level.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Exhaust Emissions
The CO
2
value measured in the EU type
approval procedure is specified at
www.stihl.com/co2.
The measured CO
2
value was
determined on a representative engine
in accordance with a standardized test
procedure under laboratory conditions
and does not represent either an explicit
or implied guarantee of the performance
of a specific engine.
The applicable exhaust emission
requirements are fulfilled by the
intended usage and maintenance
described in this instruction manual. The
type approval expires if the engine is
modified in any way.
Specifications
Displacement: 27.2 cc
Bore: 34 mm
Stroke: 30 mm
Engine power to
ISO 8893:
0.8 kW (1.1 bhp)
at 8,500 rpm
Idle speed: 2,800 rpm
Cut-off speed (rated): 10,000 rpm
Spark plug (resistor
type): NGK CMR 6 H
Electrode gap: 0.5 mm
Fuel tank capacity: 340 cc (0.34 l)
dry, without KombiTool
KM 56 RC with ErgoStart: 4.3 kg
for FCS
-
KM, FCB
-
KM,
FS
-
KM, FSB-KM, FH
-
KM
and HT
-
KM 1 to 1
for HL
-
KM 1 to 4
for BF
-
KM, KB
-
KM, KW
-
KM,
BG
-
KM and SP
-
KM 1 to 6
KM 56 RC: 90 dB(A) ... 96 dB(A)
KM 56 RC: 103 dB(A) ... 109 dB(A)
Handle, left
KM 56 RC: 4.7 m/s
2
... 8.5 m/s
2
Handle, right
KM 56 RC: 4.8 m/s
2
... 8.2 m/s
2

Stihl KM 56 RC Specifications

General

Displacement	27.2 cm³
Fuel Capacity	0.33 l
Power Source	Gasoline
Idle Speed	2, 800 rpm
Fuel Tank Capacity	0.33 l
Engine Power	0.8 kW
Engine	2-stroke
Ignition System	Electronic
Starter System	STIHL ErgoStart (E)
