Stihl MS 171 User Manual

MS 171, MS 181, MS 181 C, MS 211, MS 211 C
English
29
N turn the adjusting wheel (4) a little
until the chain sprocket cover can
be slid completely against the
engine housing
N Swing grip (5) into position (until it
engages)
N Fit wing nut and tighten lightly
N Next step: see "Tensioning the Saw
Chain"
Retensioning during cutting work:
N Switch off the engine.
N Loosen the nut.
N Hold the bar nose up.
N Use a screwdriver to turn the
tensioning screw (1) clockwise until
the chain fits snugly against the
underside of the bar.
N While still holding the bar nose up,
tighten down the nut firmly.
N Go to "Checking Chain Tension".
A new chain has to be retensioned more
often than one that has been in use for
some time.
N Check chain tension frequently –
see chapter on "Operating
Instructions".
Retensioning during cutting work:
N Shut off the engine.
N Pull out the hinged clip and loosen
the wingnut.
N Turn the adjusting wheel (1)
clockwise as far as stop.
N Tighten down the wingnut (2) firmly
by hand.
N Fold down the hinged clip.
N Go to "Checking Chain Tension"
A new chain has to be retensioned more
often than one that has been in use for
some time.
N Check chain tension frequently –
see chapter on "Operating
Instructions".
Tensioning the Saw Chain
(side chain tensioner)
1
142BA063 KN
Tensioning the Saw Chain
(quick chain tensioner)
1
2
001BA112 KN

Stihl MS 171 Specifications

General

Idle speed	- RPM
Motor type	2-stroke motor
Chain pitch	3/8 \
Blade length	350 mm
Product color	Black, Grey, Orange
Chain tensioner	Yes
Motor speed (max)	10000 RPM
Fuel tank capacity	0.266 L
Engine displacement	31.8 cm³
Power source	Gasoline
Sound power level	112 dB
Vibration emission	4.5 m/s²
Sound pressure level	99 dB
