49MS 192 T
: Fit the switch shaft (1), pushing
the rear contact spring (3) slightly
to the side.
Check operation:
The contact springs are fitted in the
handle housing at different depths.
This means that the rear contact
217RA166 TG
1
2
3
spring (3) and the front contact
spring (2) must make contact with
the metal pin of the switch shaft
when the switch shaft (1) is in
position "0".
– Reassemble parts in reverse
order.
– Set the air gap between ignition
coil and flywheel
b 9.1.1
– Reassemble remaining parts in
reverse order.
– Tightening torques, b 3.5

Stihl MS 192 T Specifications

General

Engine Displacement	30.1 cc
Recommended bar length	30 cm
Engine Power	1.3 kW
Guide Bar Length	30-35 cm
Fuel Capacity	0.27 liters
Chain Oil Capacity	0.22 liters
Chain pitch	3/8"
