Stihl MS 192 T Manual

72 MS 192 T
: Press the nipple into the mount
(arrow) inside the tank.
– Screw in the filler cap.
– Test for leaks.
217RA312 TG
Dirty air filters reduce engine power,
increase fuel consumption and
make starting more difficult.
The air filter should be checked
when there is a noticeable loss of
engine power.
– Refer also to troubleshooting,
b 4.7
: Turn the twist lock (arrow)
anticlockwise.
– Remove the carburetor box
cover (1).
217RA008 TG
1
: Press the tabs (arrows) together
and push the twist lock (1) out of
the carburetor box cover.
1
217RA330 TG
: Remove the air filter (1).
– Knock out the filter or blow it clear
with compressed air from the
inside outwards.
1
217RA314 TG
: Take the foam inlay (1) out of the
filter base.
– Clean away loose dirt from
around the filter.
Check the filter and foam inlay and
replace them if damaged or dirty.
1
217RA315 TG
– If soiled, wash all parts of the filter
in STIHL universal cleaner or a
fresh, non-flammable cleaning
solution (e.g. warm soapy water)
and allow to dry.
Do not clean fleece (non-woven)
filters with a brush.
– Reassemble parts in reverse
order.
14. Fuel System
14.1 Air Filter

Stihl MS 192 T Specifications

General

Engine Displacement	30.1 cc
Recommended bar length	30 cm
Engine Power	1.3 kW
Guide Bar Length	30-35 cm
Fuel Capacity	0.27 liters
Chain Oil Capacity	0.22 liters
Chain pitch	3/8"
