Stihl MS 192 T Manual

51MS 192 T
Check flywheel:
– Have pole shoes turned blue?
– Replace flywheel if necessary
b 9.5
Air gap:
– Check ignition module / flywheel,
– Adjust if necessary, b 9.1.1
Check ignition lead:
– Severe chafing?
– Spark plug boot: holes / cracks?
– Resistance of spark plug boot to ground:
required: 1.5...12 kW
– Check resistance of ignition lead:
value required < 10 W,
– Replace spark plug boot and/or ignition lead
with ignition module if necessary
b 9.4
Check short circuit wire:
– Replace short circuit wire if necessary
b 9.6.1
1
3
yes
no
Spark
present?
2

Stihl MS 192 T Specifications

General

Engine Displacement	30.1 cc
Recommended bar length	30 cm
Engine Power	1.3 kW
Guide Bar Length	30-35 cm
Fuel Capacity	0.27 liters
Chain Oil Capacity	0.22 liters
Chain pitch	3/8"
