MS 192 T, MS 192 TC
English
38
Removing
N Pull off the spark plug boot (1).
N Unscrew the spark plug (2).
N Push the locking strip (3) – narrow
end first – into the cylinder and then
turn it 180°.
N Rotate the clutch clockwise as far as
stop
N Loosen the clutch hexagon
clockwise (left-hand thread).
N Unscrew the clutch.
N Pull the chain sprocket (4) and
needle cage (5) off the crankshaft.
N Clean the crankshaft stub and
needle cage, and lubricate with
STIHL grease (special accessory).
Installing
N Push the needle cage and chain
sprocket onto the crankshaft.
N Screw the clutch onto the
crankshaft (counterclockwise).
N Tighten down the clutch firmly.
N Remove the locking strip from the
cylinder. Fit the spark plug and
tighten it down firmly.
N Refit boot on the spark plug.
Cutting effortlessly with a correctly
sharpened chain
A properly sharpened chain slices
through wood effortlessly and requires
very little feed pressure.
Do not work with a dull or damaged
chain as it will increase the physical
effort required, produce unsatisfactory
results and a higher rate of wear.
N Clean the chain.
N Check the chain for cracks in the
links and damaged rivets.
N Replace any damaged or worn
parts of the chain and match the
new parts to the shape and size of
the original parts.
Carbide-tipped saw chains (Duro) are
particularly wear resistant. STIHL
recommends you have your chain
resharpened by a STIHL servicing
dealer.
Maintaining and
Sharpening the Saw Chain
It is absolutely essential to comply
with the angles and dimensions
specified below. If the saw chain is
incorrectly sharpened – and in
particular if the depth gauge is set
too low – there is a risk of
increased kickback of the saw,
with resulting risk of injury.
