Stihl MS 201 C

MS 201, MS 201 C
English
42
Version with Easy2Start
N Remove remaining rope from the
rotor and starter grip
N Thread the new starter rope through
the starter grip and secure it by
making a knot
Installing the rope rotor
Version with ElastoStart
N Thread the rope from above through
the rope guide bush (1) and rope
rotor (2) and secure with a simple
overhand knot
N Coat the bearing bore in the rope
rotor with non-resinous oil
N Slip the rope rotor onto the starter
post (3) – turn it back and forth a
little until the anchor loop of the
rewind spring engages
N Refit the pawl (4) in the rotor and
slip the washer (5) over the starter
post
N Press the spring clip (6) on to the
starter post and over the pegs of the
pawl with a screwdriver or suitable
pliers – the spring clip must point in
the clockwise direction – as shown
in the picture
213BA018 KN
1
0011BA025 KN
2
5
4
6
0011BA026 KN
