Stihl MS 211 C-BE

Drawing C Cylinder, Muffler
Reference Item number Qty Description
(1)MS211, (2)MS211C-BE, (3)MS211-Z, (4)MS211C-BEZ
MS 211, MS 211 C
6
SCS 01-2010 3.29
1 1139 020 1202 1 Cylinder with piston Ø 40 mm
☐ 2-6
2 1139 030 2001 1 Piston Ø 40 mm
☐ 3-5
3 1123 034 3005 2 Piston ring Ø 40x1.2 mm
4 1132 034 1501 1 Piston pin 10x6.5x25
5 9463 650 1000 2 Snap ring 10
6 9075 478 4195 4 Pan head self-tapping screw IS-D5.3x41
7 1139 030 0401 1 Crankshaft (25.2005)
8 9503 003 0311 2 Grooved ball bearing 6002
9 9638 003 1581 2 Oil seal 15x25x5 (20.2007)
10 9639 003 1585 2 Oil seal 15x25x5 (20.2007)
11 9468 621 1520 1 Circlip 15x1
12 1139 021 2503 1 Engine pan
13 0000 400 7011 1 Spark plug NGK CMR6H
14 1139 140 0604 1 Muffler (1,2)
15 1139 140 0603 1 Muffler (3,4) USA, AUS, CDN
☐ 16
16 1139 141 9000 1 Screen (3,4) USA, AUS, CDN
17 1139 141 3201 1 Cooling plate
18 9075 478 4085 2 Pan head self-tapping screw IS-D5x18
19 1135 145 9002 2 Plug
20 0783 830 2000 1 Tube of sealant Dirko HT red
