62
English / USA
MS 361 C
EPA / CEPA:
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
A = 300 hours
B = 125 hours
C = 50 hours
CARB:
The Emission Compliance Period used
on the CARB Air Index Label indicates
the terms:
Extended = 300 hours
Intermediate = 125 hours
Moderate = 50 hours
Engine
STIHL single cylinder two-stroke engine
Magneto ignition system
Electronic (breakerless)
Spark plug (resistor type)
Bosch WSR 6 F, NGK BPMR 7 A
Electrode gap
0.02 in (0.5 mm)
Carburetor
All position diaphragm carburetor with
integral fuel pump
Fuel capacity:
1.45 US pt (0.685 l)
Chain lubrication
Fully automatic speed-controlled rotary
piston oil pump. Additional manual oil
flow control.
Oil tank capacity:
0.69 US pt (0.325 l)
Weight (without bar and chain)
12.6 lb (5.7 kg)
Cutting Attachment
Recommended cutting attachments for
compliance with § 5.11 of ANSI standard
B 175.1-2000
(see page 14 of this manual):
STIHL reduced kickback bar
(with green label) for 3/8" pitch:
Rollomatic with sprocket nose
16, 18 or 20" (40, 45 or 50 cm)
STIHL low kickback chain
1)
(with green label)
for 325" pitch:
Rapid Micro 2 (23 RM2, 26 RM2)
Rapid Micro C3 (23 RMC3, 26 RMC3)
for 3/8" pitch:
Rapid Micro 2 (33 RM2, 36 RM2)
Rapid Super C3 (33 RSC3, 36 RSC3)
Chain sprocket:
9-tooth for .325" pitch
7-tooth for 3/8" pitch
1) see definition of "low kickback chain"
on page 17.
Displacement: 3.6 cu.in (59 cm
3
)
Bore: 1.85 in (47 mm)
Stroke: 1.34 in (34 mm)
Idle speed 2800 rpm
Specifications
