Stihl MS 460 Service Manual

6 MS 460, MS 460 C
3.5 Tightening Torques
DG and P screws (Plastoform) are used in polymer and light metal components. These screws form a
permanent thread when they are installed for the first time. They can be removed and installed as often as
necessary without impairing the strength of the screwed assembly, providing the specified tightening torque is
observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque Remarks
Nm
Screw IS-M4x8 Chain tensioner cover plate 3.0
Starter post M7x12.5 Starter post/fan housing 12.0
Screw IS-M4x12 Brake band/crankcase 3.0 2)
Collar screw M8x21.5 Guide bar 23.0 2)
Screw IS-M4x12 Cover on oil pump/sprocket side 3.0
Screw IS-M4x12 Cover/crankcase, sprocket side 3.0
M10x1 Decompression valve 14.0
Nut M5 Filter cover 1.0
Collar nut M5 SK6 Flange/air filter 6.0
Screw B 4.2x9.5 Spark arresting screen
(Z version only)
6)
Screw IS-M4x12 Generator (W version only) 3.5 1)7)
Screw IS-P6x21.5 Handlebar, top 8.0 1)
Screw IS-P6x19 Handlebar, bottom 8.0 1)
Screw IS-P4x19 Handle molding 1.6
Screw IS-M5x35 Hand guard, left 7.0
Screw IS-M5x16 Shroud/crankcase 7.0
Locknut M5 Chain catcher/spiked bumper 6.0 3)
Screw IS-M5x20 Chain catcher/spiked bumper/
crankcase, bottom
7.5
Screw IS-M5x12 Spiked bumper/crankcase, top/nut 7.5 2)
Locknut M5 Chain sprocket cover/spiked bumper 7.5
Screw IS-M5x20 Crankcase 11.5
Screw IS-M5x20 Fan housing 7.0
Carrier M12x1L Carrier 50.0
Slotted nut M5 Baffle/air filter/carburetor 2.5
Nut M8x1 Crankshaft (flywheel) 33.0
Remarks:
1) Secure screw with Loctite 649
2) Secure screw with Loctite 243
3) Only machines with wrap-around handle
6) Only machines with spark arresting screen
7) Only machines with handle heating

Stihl MS 460 Specifications

General

Chain Pitch	3/8"
Engine Power	4.4 kW (6.0 bhp)
Displacement	76.5 cc
Weight	6.6 kg
Guide Bar Length	40-63 cm (16-25 inches)
