Stihl MS 461 User Manual

MS 461 R
English
47
N If engine performance deteriorates,
check the spark arresting screen in
the muffler
Guard plate
N Let the muffler cool down
N Remove the guide bar and saw
chain
The following screwed assemblies are
secured with adhesive (Loctite 243).
Before assembly, the screws must be
coated with Loctite 243 or an equivalent
adhesive – if necessary, have this done
by an authorized STIHL dealer.
N Remove screws (1)
N Remove chain catcher (2) and
guard plate (3)
Spark arresting screen
N Remove four screws
N Remove exhaust casing (1) of the
muffler
N Bend back the retaining lugs (2)
N Pull out spark arresting screen (3)
N Clean the dirty spark arresting
screen, replace if damaged or
heavily carbonized
N Refit the spark arresting screen in
reverse order of steps
If engine is down on power, difficult to
start or runs poorly at idling speed, first
check the spark plug.
Fit a new spark plug after approx. 100
operating hours or earlier if the
electrodes are badly eroded.
Wrong fuel mix (too much engine oil in
the gasoline), a dirty air filter and
unfavorable running conditions (mostly
at part throttle etc.) affect the condition
of the spark plug. These factors cause
deposits to form on the insulator nose
which may result in trouble in operation.
Removing the spark plug
N Turn the knob above the rear handle
in the direction of the arrow and
remove the carburetor box cover
Spark Arresting Screen in
Muffler
1
1
179BA006 KN
1
2
3
3443BA009 KN
1
3
2
3443BA010 KN
Spark Plug
145BA027 K

Stihl MS 461 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.325 L
Fuel tank capacity	0.8 L
Engine displacement	76.5 cm³
Engine power	6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6700 g
