MS 461 R
English
48
N Lift the air baffle (1) up and off
N Unplug spark plug boot (2)
N Unscrew spark plug
Checking the Spark Plug
N Clean dirty spark plug.
N Check electrode gap (A) and
readjust if necessary – see
"Specifications."
N Use only resistor type spark plugs of
the approved range.
Rectify problems that have caused
fouling of spark plug:
– too much oil in fuel mix,
– dirty air filter,
– unfavorable running conditions, e.g.
operating at part load.
WARNING
To reduce the risk of fire and burn injury,
use only spark plugs authorized by
STIHL. Always press spark plug boot (1)
snugly onto spark plug terminal (2) of the
proper size. (Note: If terminal has
detachable SAE adapter nut, it must be
securely attached.) A loose connection
between spark plug boot and ignition
wire connector in the boot may create
arcing that could ignite combustible
fumes and cause a fire.
Installing the spark plug
N Screw in the spark plug
N Press on the spark plug boot (1)
firmly
N Insert the air baffle (2) from above
N Mount carburetor box cover
145BA039 KN
2
1
000BA039 KN
A
1
2
000BA071 KN
2
1
3443BA011 KN

Stihl MS 461 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Automatic oiling	Yes
Oil tank capacity	0.325 L
Fuel tank capacity	0.8 L
Engine displacement	76.5 cm³
Engine power	6 hp
Power source	Gasoline

Weight and Dimensions

Weight	6700 g
