MSE 170 C, MSE 190 C, MSE 210 C, MSE 230 C
English
40
Cutting Attachment (MSE 170 C)
Actual cutting length may be less than
the specified length
Rollomatic E Mini Light guide bars
Rollomatic E Mini guide bars
3/8" Picco chain
Rollomatic E guide bars
3/8" Picco chain
Carving guide bars
1/4" chains
Chain sprocket
Cutting Attachment (MSE 190 C,
MSE 210 C, MSE 230 C)
Actual cutting length may be less than
the specified length
Rollomatic E Light and Rollomatic E
guide bars
3/8" Picco chain
Rollomatic E guide bars
3/8" Picco chain
Carving guide bars
1/4" chains
Chain sprocket
MSE 190 C
Cutting lengths: 25, 30, 35 cm
Pitch:
3/8" P
(9.32 mm)
Groove width: 1.1 mm
Nose sprocket: 7-tooth
Cutting lengths: 30, 35, 40 cm
Pitch:
3/8" P
(9.32 mm)
Groove width: 1.1 mm
Nose sprocket: 7-tooth
Picco Micro Mini 3 (61 PMM3)
Type 3610
Pitch: 3/8" P
(9.32 mm)
Drive link gauge: 1.1 mm
Cutting lengths: 30, 35, 40 cm
Pitch:
3/8" P
(9.32 mm)
Groove width: 1.3 mm
Nose sprocket: 9-tooth
Picco Micro 3 (63 PM3) Type 3636
Picco Duro 3 (63 PD3) Type 3612
Pitch: 3/8" P
(9.32 mm)
Drive link gauge: 1.3 mm
Cutting lengths: 25, 30 cm
Pitch: 1/4" (6.35 mm)
Groove width: 1.3 mm
Rapid Micro Spezial (13 RMS)
Type 3661
Pitch: 1/4" (6.35 mm)
Drive link gauge: 1.3 mm
6-tooth for 3/8" P
8-tooth for 1/4"
Cutting lengths: 30, 35, 40 cm
Pitch:
3/8" P
(9.32 mm)
Groove width: 1.3 mm
Nose sprocket: 9-tooth
Picco Micro 3 (63 PM3) Type 3636
Picco Duro 3 (63 PD3) Type 3612
Pitch: 3/8" P
(9.32 mm)
Drive link gauge: 1.3 mm
Cutting lengths: 45 cm
Pitch:
3/8" P
(9.32 mm)
Groove width: 1.3 mm
Nose sprocket: 9-tooth
Picco Micro 3 (63 PM3) Type 3636
Pitch: 3/8" P
(9.32 mm)
Drive link gauge: 1.3 mm
Cutting lengths: 25, 30 cm
Pitch: 1/4" (6.35 mm)
Groove width: 1.3 mm
Rapid Micro Spezial (13 RMS)
Type 3661
Pitch: 1/4" (6.35 mm)
Drive link gauge: 1.3 mm
6-tooth for 3/8" P
8-tooth for 1/4"
