Stihl RE 232 - Transporting the Unit

RE 232, RE 272 PLUS, RE 282 PLUS
English
10
with water filter
N Remove protective cap (1) from the
water inlet
N Fit and attach the union nut of the
water filter (2) and tighten it by hand
N Attach the hose connector (3) and
tighten it by hand
Machines without hose reel
Connector on high-pressure connection
N Push seal (1) unto the high-
pressure hose
N Screw on and tighten the
connecting element (2)
Machines with hose reel
N Push the knob (1) unto the crank (2)
of the hose reel until it engages
Pushing the pressure washer
N Hold the pressure washer firmly with
both hands on the pushbar (1)
N Steady the pressure washer with
your foot on the kick plate (2), press
pushbar (1) downward and balance
the pressure washer
3
2
1
6158BA002 KN
1
2
6158BA003 KN
1
2
6158BA004 KN
Transporting the Unit
1
6158BA009 KN
2
