- 22 -
Mode Burst C – 0.75 second Burst sequence = 0.25s on,
0.5s off. Both Pulse Rate and Pulse Width are adjustable.
Default values are PR=100Hz and PW=150μs. The
stimulation level must be set to produce a gentle
muscular contraction.
EMS:
Intensity 0-150mA zero to peak at 1000ohm
load
Frequency 1-120 Hz
Pulse width Positive phase: 50-400μs, in steps of
50μs
Waveform Symmetrical Bi-Phasic rectangular,
Alternated Bi-Phasic rectangular
Ramp up time 0-8s in steps of 1s
Ramp down time 0-8s in steps of 1s
On time 1-60s in steps of 1s
Off time 0-60s in steps of 1s
Treatment timer Continuous, 10, 20, 30, 45, 60, 90min
Program 32&33 (manual) – When using ALTERNATIING
Frequency
, ensure that the “Ramp Up Time”, “On Time”,
and “Ramp Down Time” equals “Off Time”.
Ramp Up + On Time + Ramp Down = Off Time
The will appear on your screen if this formula is not
followed in EMS manual mode.
