Stinger Quad-Aer - Operational Adjustments; Tracking Adjustment

7
Tracking Adjustment
Forward Adjustment:
1. Slide the rod end clip up (gure 5) and gently pull rod away
from the hydrostac motor.
2. Turn the rod end clockwise to increase or counterclockwise to
decrease speed on that side.
Reverse Speed Limiter:
1. Loosen bolt (See gure 6) and slide stop forward to decrease
or backwards to increase reverse travel speed.
2. Reghten bolt.
Figure 5
Figure 6
