Operating instructions
AIROMATIC PS4500 | TARGA PS6000 | PERGOLINO P3500
Locking and tautening the fabric panel (only PERGOLINO model)
To tauten the fabric panel, proceed as follows:
1. Ensure that the travel path of the fabric pan-
el is clear.
2. Use the channel selection button
on the
remote control to select the channel for the
shade.
Î The diode of the selected channel flash-
es red.
3. Press the DOWN
button to extend the
shade fabric panel.
Î The fabric panel extends completely.
Fig. 18: Apply stop block
4. Insert the left and rights stop blocks with the
hook rod (fig. 18/1). Push up the fabric stop
block (fig. 18/2).
5. Press the UP
button to retract the fabric
panel of the shade.
Î The fabric panel is pulled back, held by the
lock function and thus tightened. When the
fabric panel is taut, the motor stops.
