Stobag Select - Fixing Bracket Distribution: 4 Folding Arms (Continued); 180 cm - 250 cm

www.stobag.com
- 10 -
180cm 4 x S834
625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000 1025 1050 1075 1100 1125 1150 1175 1200
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 15 15 20 20 25 25 30 30 35 35
A1 b 10 10 10 10 10 10 15 15 15 20 20 20 25 25 30 30 35 35 40 40 45 45 50 50
K2 c 25 25 25 25 25 25 30 30 30 35 35 35 40 40 --- --- --- --- --- --- --- --- --- ---
W1 d --- --- --- --- --- --- --- --- --- --- --- --- 276 285 295 303 313 322 332 340 350 355 365 374
K3 e --- --- --- --- --- --- --- --- --- --- --- --- 288 297 307 315 325 334 344 352 362 370 380 389
A2 f 194 202 210 219 227 235 245 254 262 272 280 289 300 309 319 327 337 346 356 364 374 385 395 404
K4 g 209 217 225 234 242 250 260 269 277 287 295 304 --- --- --- --- --- --- --- --- --- --- --- ---
K5 h 297 310 322 335 347 360 372 385 397 410 422 435 462 475 487 500 512 525 537 550 562 575 587 600
W2 i 312 325 337 350 362 375 387 400 412 425 437 450 --- --- --- --- --- --- --- --- --- --- --- ---
200cm 4 x S834
625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000 1025 1050 1075 1100 1125 1150 1175 1200
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 15 15 20 20 25 25 30 30 35 35
A1 b 10 10 10 10 10 10 15 15 15 20 20 20 25 25 30 30 35 35 40 40 45 45 50 50
K2 c 25 25 25 25 25 25 30 30 30 35 35 35 40 40 --- --- --- --- --- --- --- --- --- ---
W1 d --- --- --- --- --- --- --- --- --- --- --- --- 270 279 289 297 307 316 326 334 344 352 362 371
K3 e --- --- --- --- --- --- --- --- --- --- --- --- 283 292 302 310 320 329 339 347 357 365 375 384
A2 f 194 202 210 219 227 235 245 254 262 272 280 289 298 307 317 325 335 344 354 362 372 380 390 399
K4 g 209 217 225 234 242 250 260 269 277 287 295 304 --- --- --- --- --- --- --- --- --- --- --- ---
K5 h 297 310 322 335 347 360 372 385 397 410 422 435 462 475 487 500 512 525 537 550 562 575 587 600
W2 i 312 325 337 350 362 375 387 400 412 425 437 450 --- --- --- --- --- --- --- --- --- --- --- ---
225cm 4 x S834
625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000 1025 1050 1075 1100 1125 1150 1175 1200
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 15 15 20 20 25 25 30 30 35 35
A1 b 10 10 10 10 10 10 15 15 15 20 20 20 25 25 30 30 35 35 40 40 45 45 50 50
K2 c 25 25 25 25 25 25 30 30 30 35 35 35 40 40 --- --- --- --- --- --- --- --- --- ---
W1 d --- --- --- --- --- --- --- --- --- --- --- --- 265 274 284 292 302 311 322 330 340 349 358 367
K3 e --- --- --- --- --- --- --- --- --- --- --- --- 280 289 299 314 317 326 337 345 355 364 373 382
A2 f 181 193 205 218 224 232 242 250 259 269 277 285 295 304 314 322 332 341 352 360 370 379 388 397
K4 g 196 208 220 233 239 247 257 265 274 284 292 300 --- --- --- --- --- --- --- --- --- --- --- ---
K5 h 297 310 322 335 347 360 372 385 397 410 422 435 462 475 487 500 512 525 537 550 562 575 587 600
W2 i 312 325 337 350 362 375 387 400 412 425 437 450 --- --- --- --- --- --- --- --- --- --- --- ---
250cm 4 x S834
625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000 1025 1050 1075 1100 1125 1150 1175 1200
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 15 15 20 20 25 25 30 30 35 35
A1 b 10 10 10 10 10 10 10 15 15 20 20 20 25 25 30 30 35 35 40 40 45 45 50 50
K2 c 25 25 25 25 25 25 25 30 30 35 35 35 40 40 --- --- --- --- --- --- --- --- --- ---
W1 d --- --- --- --- --- --- --- --- --- --- --- --- 277 287 296 306 315 324 333 342 351 360 370 379
K3 e --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
A2 f 162 177 189 205 214 227 238 248 257 266 275 283 292 302 311 321 330 339 348 357 366 375 385 394
K4 g 177 192 204 217 229 242 252 263 272 281 290 298 307 317 326 336 345 354 363 372 381 390 400 409
K5 h 297 310 322 335 347 360 372 385 397 410 422 435 462 475 487 500 512 525 537 550 562 575 587 600
W2 i 312 325 337 350 362 375 387 400 412 425 437 450 --- --- --- --- --- --- --- --- --- --- --- ---
275cm 4 x S834
625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000 1025 1050 1075 1100 1125 1150 1175 1200
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 15 15 20 20 25 25 30 30 35 35
A1 b --- 10 10 10 10 10 15 15 15 20 20 20 25 25 30 30 35 35 40 40 45 45 50 50
K2 c --- 25 25 25 25 25 30 30 30 35 35 35 40 40 --- --- --- --- --- --- --- --- --- ---
W1 d --- --- --- --- --- --- --- --- --- --- --- --- 277 287 296 306 315 324 333 342 351 360 370 379
K3 e --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
A2 f --- 163 175 188 200 214 225 238 251 263 274 283 292 302 311 321 330 339 348 357 366 375 385 394
K4 g --- 178 190 203 215 229 240 253 266 278 289 298 307 317 326 336 345 354 363 372 381 390 400 409
K5 h --- 310 322 335 347 360 372 385 397 410 422 435 462 475 487 500 512 525 537 550 562 575 587 600
W2 i --- 325 337 350 362 375 387 400 412 425 437 450 --- --- --- --- --- --- --- --- --- --- --- ---
