Stobag Select - Fixing Bracket Distribution: 6 Folding Arms (Continued); 250 cm - 300 cm

www.stobag.com
- 14 -
250cm 6 x S834
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a --- --- --- --- --- --- --- --- --- 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35
A1 b 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35 40 40 40 45 45 45 50 50 50
K2 c 30 30 30 35 35 35 40 40 40 --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
W1 e --- --- --- --- --- --- --- --- --- --- --- --- 296 301 306 314 319 324 331 336 341 349 354 359
A2 f 237 243 247 255 260 265 273 278 283 291 296 301 309 314 319 327 332 337 344 349 354 362 367 372
K4 g 252 258 262 270 275 280 288 293 298 306 311 316 324 329 334 342 347 352 359 364 369 377 382 387
W2 h 432 442 452 462 472 482 494 504 514 525 535 545 --- --- --- --- --- --- --- --- --- --- --- ---
K5 i 451 461 471 482 492 502 513 523 533 543 554 564 575 585 595 606 616 626 636 646 656 666 677 687
A3 j 466 476 486 497 507 517 528 538 548 559 569 579 590 600 610 621 631 641 651 661 671 681 692 702
K6 k --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K7 l --- --- --- --- --- --- --- --- --- --- --- --- 748 760 772 785 797 810 822 835 847 860 872 885
W3 m --- --- --- --- --- --- --- --- --- --- --- --- 762 775 787 800 812 825 837 850 862 875 887 900
275cm 6 x S834
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a --- --- --- --- --- --- --- --- --- 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35
A1 b 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35 40 40 40 45 45 45 50 50 50
K2 c 30 30 30 35 35 35 40 40 40 --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
W1 e --- --- --- --- --- --- --- --- --- --- --- --- 296 301 306 314 319 324 331 336 341 349 354 359
A2 f 229 235 241 251 257 264 273 278 283 291 296 301 309 314 319 327 332 337 344 349 354 362 367 372
K4 g 244 250 256 266 272 279 288 293 298 306 311 316 324 329 334 342 347 352 359 364 369 377 382 387
W2 h 420 427 446 460 472 486 494 504 514 525 535 545 --- --- --- --- --- --- --- --- --- --- --- ---
K5 i 435 449 461 475 487 501 513 523 533 543 554 564 575 585 595 606 616 626 636 646 656 666 677 687
A3 j 450 464 476 490 502 516 528 538 548 559 569 579 590 600 610 621 631 641 651 661 671 681 692 702
K6 k --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K7 l --- --- --- --- --- --- --- --- --- --- --- --- 748 760 772 785 797 810 822 835 847 860 872 885
W3 m --- --- --- --- --- --- --- --- --- --- --- --- 762 775 787 800 812 825 837 850 862 875 887 900
300cm 6 x S834 / S833
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a --- --- --- --- --- --- --- --- --- 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35
A1 b 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35 40 40 40 45 45 45 50 50 50
K2 c 30 30 30 35 35 35 40 40 40 --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
W1 e --- --- --- --- --- --- --- --- --- --- --- --- 293 298 303 311 316 321 329 334 339 347 352 357
A2 f 222 226 235 251 256 261 269 274 279 284 291 297 305 310 315 323 328 333 341 346 351 359 364 369
K4 g 237 241 250 266 271 276 284 289 294 299 306 312 320 325 330 338 343 348 356 361 366 374 379 384
W2 h 420 427 434 449 465 475 485 504 514 524 535 545 --- --- --- --- --- --- --- --- --- --- --- ---
K5 i --- --- 447 462 484 494 505 515 525 535 546 556 567 577 587 598 608 618 629 639 649 660 670 680
A3 j 437 450 462 477 499 509 520 530 540 550 561 571 582 592 602 613 623 633 644 654 664 675 685 695
K6 k 452 465 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K7 l --- --- --- --- --- --- --- --- --- --- --- --- 748 760 772 785 797 810 822 835 847 860 872 885
W3 m --- --- --- --- --- --- --- --- --- --- --- --- 762 775 787 800 812 825 837 850 862 875 887 900
325cm 6 x S833
1225 1250 1275 1300 1325 1350 1375 1400 1425 1450 1475 1500 1525 1550 1575 1600 1625 1650 1675 1700 1725 1750 1775 1800
K1 a --- --- --- --- --- --- --- --- --- --- --- 15 15 15 20 20 20 25 25 25 30 30 30 30
A1 b 10 10 15 15 15 20 20 20 25 25 25 30 30 30 35 35 35 40 40 40 45 45 45 45
K2 c 25 25 30 30 30 35 35 35 40 40 40 --- --- --- --- --- --- --- --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
W1 e --- --- --- --- --- --- --- --- --- --- --- --- 287 292 300 305 310 319 324 328 336 342 347 352
A2 f 210 217 226 234 241 258 263 268 276 282 288 294 299 304 312 317 322 331 336 340 348 354 359 364
K4 g 225 232 241 249 256 273 278 283 291 297 303 309 314 319 327 332 337 346 351 355 363 369 374 379
W2 h 392 402 416 430 444 476 486 496 503 512 520 536 --- --- --- --- --- --- --- --- --- --- --- ---
K5 i 407 417 431 445 459 491 501 511 518 527 542 553 563 573 585 595 605 615 625 635 645 655 665 675
A3 j 422 432 446 460 474 506 516 526 533 542 557 568 578 588 600 610 620 630 640 650 660 670 680 690
K6 k --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K7 l --- --- --- --- --- --- --- --- --- --- --- --- 748 760 772 785 797 810 822 835 847 860 872 885
W3 m --- --- --- --- --- --- --- --- --- --- --- --- 762 775 787 800 812 825 837 850 862 875 887 900
