Stobag Select - Fixing Bracket Distribution: 2 Folding Arms (Extended Sizes); 225 cm - 350 cm

www.stobag.com
- 8 -
225cm 2 x S834
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- 25 30 35 40 45 50 55
A1 b --- --- --- --- 10 10 15 20 25 30 35 40 45 50 55 60 65 70
K2 c --- --- --- --- 25 25 30 35 40 45 50 --- --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K4 e --- --- --- --- --- --- --- --- --- --- 212 225 237 250 262 275 287 300
250cm 2 x S834
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- --- 25 30 35 40 45 50
A1 b --- --- --- --- --- 10 10 15 20 25 30 35 40 45 50 55 60 65
K2 c --- --- --- --- --- 25 25 30 35 40 45 50 --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K4 e --- --- --- --- --- --- --- --- --- --- 212 225 237 250 262 275 287 300
275cm 2 x S834
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- 25 30 35 40 45
A1 b --- --- --- --- --- --- 10 10 15 20 25 30 35 40 45 50 55 60
K2 c --- --- --- --- --- --- 25 25 30 35 40 45 50 --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K4 e --- --- --- --- --- --- --- --- --- --- 212 225 237 250 262 275 287 300
300cm 2 x S834 / S833
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- 25 30 35 40
A1 b --- --- --- --- --- --- --- 10 10 15 20 25 30 35 40 45 50 55
K2 c --- --- --- --- --- --- --- 25 25 30 35 40 45 50 --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K4 e --- --- --- --- --- --- --- --- --- 200 212 225 237 250 262 275 287 300
325cm 2 x S833
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 25 35 40
A1 b --- --- --- --- --- --- --- --- --- 10 15 20 25 30 35 40 50 55
K2 c --- --- --- --- --- --- --- --- --- 25 30 35 40 45 50 --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
K4 e --- --- --- --- --- --- --- --- --- 200 212 225 237 250 262 275 287 300
350cm 2 x S833
175 200 225 250 275 300 325 350 375 400 425 450 475 500 525 550 575 600
K1 a --- --- --- --- --- --- --- --- --- --- --- --- 10 15 20 25 30 40
A1 b --- --- --- --- --- --- --- --- --- 10 10 10 25 30 35 40 45 55
K2 c --- --- --- --- --- --- --- --- --- 25 25 25 --- --- --- --- --- ---
K3 d --- --- --- --- --- --- --- --- --- --- 40 40 40 45 50 55 60 70
K4 e --- --- --- --- --- --- --- --- --- 200 212 225 237 250 262 275 287 300
