Fig. 4
Description Qty.
Description Qty.
JJ
MM
LOOSE PARTS
A - Firebox ....................................................................... 1
B - Support
...................................................................... 3
C - Insert removal tool ..................................................... 1
D - Pizza stone ................................................................. 1
E - Leg front section ........................................................ 1
F - Leg rear section ......................................................... 1
G - Wheel ......................................................................... 2
H - Left side panel (L) ....................................................... 1
I - Right side panel (R) ....................................................1
J -
Removable grate insert .............................................. 1
K - Main grate .................................................................. 1
L - Charcoal basket ......................................................... 1
M - Charcoal grate ........................................................... 1
N - Ash canister handle ................................................... 1
O - Heat shield ................................................................. 1
P - Ash canister ...............................................................1
Q - Firebox handle ........................................................... 1
R - Hood assembly .......................................................... 1
S - Brace .......................................................................... 1
T - Base ........................................................................... 1
U - Paper basket .............................................................. 1
HARDWARE BLISTER PACK
AA - Nyloc nut (M6) .........................................................2
BB - Spacer ..................................................................... 2
CC - Round head bolt (M4 x 16 mm) ..............................3
DD - Self-tapping round head screw (M4 x 12 mm) ........ 6
EE - Cotter pin ................................................................ 2
FF - Flat washer (10 mm) ................................................ 2
GG - Axle ......................................................................... 2
HH - Round head bolt (M6 x 55 mm) ..............................4
II - Flat washer (6 mm) ................................................12
JJ - Lock washer (6 mm) ................................................ 9
KK - Hex nut (M6) ............................................................ 9
LL - Round head bolt (M6 x 16 mm) .............................. 3
MM
- Round head screw (M4 x 16 mm) ........................... 4
NN - Bolt (M6 x 62 mm) ................................................... 2
A
B
H
Q
S
T
B
B
E
F
I
C
R
D
L
J
K
M
U
P
O
N
G
EE
GG
FF
BB
AA
HH
II
KK
DD
II
LL
HH
CC
